TurboCAD Mac Pro v14

TurboCAD Mac v14 Pro

Array

$699.99
Order form
Quantity
TurboCAD Mac v14 Pro

Product Info

Professional 2D/3D Design & Rendering

TurboCAD Mac® Pro is a comprehensive 2D/3D CAD solution that will meet the precision drafting and modeling needs of architects, builders, mechanical engineers, woodworkers, and other design professionals. Our powerful CAD software will speed up your productivity and get your design projects across the finish line.
Key Features

checkmark iconACIS®-Based Solid Modeling

checkmark iconAdvanced 3D Modeling Tools

checkmark iconFeature-Based/History Tree

checkmark iconModel to Sheet

checkmark iconPhotorealistic Rendering with HDRI Support

checkmark iconFile Import & Export Support

New Features
Related Products

New Features

Mechanical Tool Palette

The unfold tool is in the mechanical tool palette located under Tools in the menu bar. Selecting the tool icon prompts the user for the surface or body to unfold.  The surface to unfold fold must have zero thickness such as with a surface or mesh object.  For example, it does not accept a solid. Select any surface in the body and the results are displayed in the XY plane at z = 0.

ACIS Modeling Engine Update

The core modeling kernel was updated to support a newer version from Spatial.  The new update provides greater increases in quality and robustness and improvements in modeling tasks such as booleans, blending, chamfering, sweeps, skinning, healing, and faceting functionality.

Paraboloid Primitive

The paraboloid primitive provides a means to create a quadric surface from one-, two-, or three-point definitions. Use a paraboloid to create a reflectors/radars, automobile headlights, solar furnaces, antennas, and aerodynamic tips.

PBR Photo Rendering

PBR, or physically based rendering, is a method of rendering computer graphics that aims to accurately represent the way that light interacts with different materials in the real world. In PBR rendering, the appearance of a material is defined by a set of parameters that describe its physical properties, such as its roughness, reflectivity, and transparency.

BOM Fraction Measurements

The Bill of Material Create BOM feature has a new option to support fraction measurements. To use this feature, select the Attributes and BOM dialog box from the Tools menu. Select your objects and associated a data set such as CutList properties. Apply to selected. Now select the Create BOM option to create a table. In the BOM Settings dialog box, select the Decimals pull down option. And then Select Fractions to display measurements as factions of feet and inches.

Key Features

ACIS®-Based Solid Modeling

TurboCAD Mac Pro provides you with ACIS Solid modeling engine. Make your models realistic with solid objects that have volume and shape as well as a framework, skin (set of surfaces) encasing the framework, and inner "body".

Advanced 3D Modeling Tools

Layout your design or import existing files for easy editing. With intuitive design tools, even novice designers can quickly create precise 3D designs.

Feature-Based/History Tree

View and revise changes and modifications performed on individual objects, groups, or blocks to assess your progress.

Model to Sheet

Use floating model space to use model space tools in paper space to create and layout your drawing in TurboCAD Mac Pro.

Photorealistic Rendering with HDR

Assign materials and luminance qualities to objects. Create a render scene environment to modify the background and foreground of your model.

File Import & Export Support

TurboCAD Mac Pro enables you to import and export data from other TurboCAD formats, as well as formats of other CAD systems.

TurboCAD Mac Pro Reviews

TurboCAD User Gallery

System Requirements

Macintosh® OS 10.11 through 13.0 or higher¹, x64 Intel® Mac®, 3 GB of hard disk space, 8 GB RAM or greater, Mouse Pointing Device (wheel button recommended), OpenGL Compliant video card with 256 MB VRAM, ¹ Program compatibility is not guaranteed for earlier operating systems, require a machine with an operating system using x64 (64-Bit) architecture.

Buy Your TurboCAD Product Now

Find the TurboCAD Mac version that best fits your needs

TurboCAD Mac Deluxe

$22999

  • 2D Drawing, Editing & Modifying
  • AutoCAD® (DXF, DWG & DWF) File Compatibility
  • 3D Solid & Surface Modeling & Editing
  • Architectural Tools
  • Photorealistic Rendering
  • 3D Printing Support
  • 2D/3D Part Library
  • -
  • -
  • -
  • -

TurboCAD Mac Designer

$6999

  • 2D Drawing, Editing & Modifying
  • AutoCAD® (DXF, DWG & DWF) File Compatibility
  • -
  • Architectural Tools (Limited)
  • -
  • -
  • -
  • -
  • -
  • -
  • -
